RISC-V: A Baremetal Introduction using C++. Conclusion.

  • The toolchain using Platform IO supported modern C++ with a small configuration change.
  • The startup code required some assembly, but was mostly was very readable C++.
  • Drivers accessed via MMIO could be completely abstracted — or wrapped to simply provide convenient access to hardware registers.
  • We could specify system clock delays in human-readable units with zero run time cost.
  • Access to special system registers could be abstracted, and I propose we can abstract standard and custom instructions via C++ to take full advantage of RISC-V.
  • Interrupts were not so simple, while we can use them as C++ lambda’s it’s not a zero-cost abstraction and the implementation was not straightforward. However, the plain old C callback works fine here.

C++ Benefits?

How useful is C++ at this level? Zero cost abstractions can be built to make software development simpler, more efficient, and also easier to verify.

  • Object oriented abstractions can be made more efficient than traditional C abstractions via static polymorphism and compile-time evaluation (constexpr/consteval).
  • The same object oriented abstractions can also simplify verification by making interfaces interchangeable, which can simplify unit testing and mock interfaces. For example, we could replace the timer driver with a host emulation version. We could even replace the MMIO and system register classes with a mock and run all this code via host emulation. Static assertions and other compile-time evaluation can check interfaces at compile-time.

C++ Downsides?

On the downside, the standard library is not specialized for resource-constrained environments and without a host operating system. The full features of the language are not available, and while the freestanding subset has been defined as a subset of the standard hosted implementation, it is still a work in progress.

RISC-V Downsides?

RISC-V is not specifically designed for embedded systems, the ARM Cortex-M series provides a better standard interrupt controller and standardized address layout for core peripherals such as the timer and interrupt controller.

RISC-V Future?

RISC-V provides an open architecture to replace older proprietary cores. It probably won't replace ARM Cortex-* — a set of modern architectures designed for embedded and mobile systems — any time soon. But in applications where custom and legacy cores, even as old as the 8051, still find use, I expect we will see it take hold. It should benefit from a readily available set of core IPs with different pricing models, maturing toolchains with investment from many companies using an open development model.

--

--
